Simulation Scripting Essentials
Automation in the 3DEXPERIENCE® platform is a powerful solution available for various domains and provides a complete set of dedicated APIs which allows users to create, model and execute the multiphysics simulations. The course starts with the basics of VB programming and then covers automation for basic 3DEXPERIENCE® platform operations, geometric modelling, materials, mesh, simulation scenarios, simulation execution and postprocessing. The course also covers GUI customization using VB for building the graphical user interface and the SIM Python API for reading/writing the SIM files.
- Level
- Fundamental
- Length
- 42 hours 15 minutes
- Product
- 3DEXPERIENCE Platform
- Delivery
- Instructor-led or eLearning
Topics covered
- Overview - Simulation Scripting Essentials10 min
- 1 - Introduction to Automation6 hour
- 2 - Objects1 hour
- 3 - Product Modeler8 hour
- 4 - Model Creation8 hour
- 5 - Materials2 hour
- 6 - VB API for Physics Scenario Apps3 hour
- 7 - Physics Results Explorer3 hour
- 8 - VBA GUI Customization3 hour
- 9 - SIM API4 hour
- 10 - Introduction to Enterprise Knowledge Language (EKL)4 hour
- Appendices Optional1 hour 10 min
Who it is for
This course is intended for the following roles:
- Structural Mechanics Engineer
- Structural Performance Engineer
Prerequisites
The following are is recommended prior to taking this course:
- Completing the Structural Simulation Essentials training course (or equivalent)
- Existing knowledge of VB scripting
