CATIADesign and Engineering
Practice CATIA Structure Functional Design
This module will teach you how to create the functional design of a ship, including such features as the hull form, the main panels, stiffeners and openings. You will learn how to use the design to generate a material report and a finite element model. You will also learn how to set up and later customize resources for the design project.
- Level
- Fundamental
- Length
- 12 hours
- Product
- 3DEXPERIENCE Platform
- Delivery
- Instructor-led or eLearning
What you will learn
- Set up the project resources
- Create a hull shell, deck and the bulkhead panels
- Place stiffeners on the panels
- Create openings and slots
- Generate a material report
- Generate a finite element model
- Generate a panel drawing
- Modify the setup by updating the resources
Topics covered
- Module Requisites: Practice CATIA Structure Functional Design0 mins
- Setting Up the Project Resources2 hours
- Introduction to Ship Design1 hours
- Creating a Basic Design of a Ship6 hours
- Exercise: Customize the Project3 hours
Prerequisites
Learners attending this module should have completed the Explore the 3DSwymer Role module.
